ENVIRO-1Xa 2C (Dual Process Chambers)
- 115 WPH (20 sec process time)
- 100 – 300 mm wafer size with ability to run 2 different sizes simultaneously in dedicated chambers
- Non-contact end effector option
- HEPA option
- Dual cassette loading:
- SMIF option
- FOUP option
ENVIRO Offers the Flexibility for Multiple Applications
- Descum
- Thick resist strip (including: SU-8, KMPR, silanated)
- Polymer and residue removal
- MEMS Release (organic sacrificial layer removal)
- Backside clean (bevel/edge)
ENVIRO Offers a Wide Process Operating Range
- Ashing Rate – Several nm/min to more than 10um/min
- Wide range of stage temperature control (hot plate or optional cold plate)
- High efficiency downstream plasma source
- Up to 4 MFC’s, 2 standard, 2 optional
- Gas chemistries: various, including halogen bearing
